VIR Ball valve PP 3/8" female thread 16bar DN10 black type 220
Product number: 0401581
Manuals & drawings
Frequently bought together
Technical details
-
DN10
-
Temperature range0°C - 75°C
-
Colour leverred
-
MaterialPP
-
Operationlever
-
Material sealPTFE
-
Type220
-
Colourblack
-
Connectionfemale thread
-
Handle materialfibreglass reinforced nylon
-
Pressure16 bar
-
Ball materialhard chrome plated brass
-
EAN4019305102681
-
Part number0401581
-
ManufacturerVIR
Dimensions
-
Ct-147 mm
-
F-114 mm
-
F-214 mm
-
Lb52 mm
-
R85 mm
-
ØDf10 mm
-
ØDi-13/8 "
-
ØDi-23/8 "
Product description
This VIR ball valve type 220 pp is suitable for all types of water applications or installations with a working temperature from 0°C to +75°C . Working pressure for this ball valve is up to 16bar.
The VIR ball valve comes with a glass fibre reinforced nylon handle and come with PTFE seals. The body of the ball valve is black.
VIR is an Italian brand, founded in 1971. Worldwide VIR is known for its wide range of valves. Located in the district of Cusio-Valsesia, VIR is at the centre of what is considered one of the most important areas in Italy for the production of valves and fittings.
