Profec Non return valve ductile iron (GGG40) epoxy coating DN250 DIN flange 10bar DN250 blue PN10

Product number: 0401936

Manuals & drawings

Select your item below or order directly via full product table
Size
All prices shown are gross prices. Please log in or contact sales for custom, discounted pricing.
Price excl. VAT 63,95 € / 1 pcs
63,95 € / pcs
Price incl. VAT 63,95 € / 1 pcs
63,95 € / pcs
1 in stock in %name%
Item %s is ready to ship, minimum delivery time: %s working days
pcs
Box qty:
4 pcs
MSQ:
1 pcs

Fast, free shipping on orders over £350*

Your trade partner in water technology

8.9/10 Read reviews

Frequently bought together

T-piece 90° PVC-U 2" imperial glue socket 16bar white
0180121
T-piece 90° PVC-U 2" imperial glue socket 16bar white

5,12 €*
Adaptor socket PVC-U 20 mm x 1/2" glue socket x female thread 16bar grey
0160817
Adaptor socket PVC-U 20 mm x 1/2" glue socket x female thread 16bar grey

0,38 €*
Cap PVC-U 2" imperial glue socket 16bar white
0180139
Cap PVC-U 2" imperial glue socket 16bar white

1,84 €*
Elbow 90° PVC-U 20 mm glue socket 16bar grey
0160106
Elbow 90° PVC-U 20 mm glue socket 16bar grey

0,34 €*
T-piece 90° PVC-U 20 mm glue socket 16bar grey
0160252
T-piece 90° PVC-U 20 mm glue socket 16bar grey

0,40 €*
Socket PVC-U 50 mm glue socket 16bar black
0152605
Socket PVC-U 50 mm glue socket 16bar black

3,72 €*
Profec Stub flange PVC-U 3/4" imperial glue socket 16bar grey WRAS
7025846
Profec Stub flange PVC-U 3/4" imperial glue socket 16bar grey WRAS

0,45 €*
Quick coupler adaptor steel galvanised 70 mm x 63 mm male part Perrot x hose tail type Perrot
0200341
Quick coupler adaptor steel galvanised 70 mm x 63 mm male part Perrot x hose tail type Perrot

10,25 €*
VDL Non return valve PVC-U 13 mm hose tail grey
7018314
VDL Non return valve PVC-U 13 mm hose tail grey

3,87 €*
Profec Socket PE100 20 mm electrofusion socket SDR11 24VAC 10bar 16bar black DVGW
7025455
Profec Socket PE100 20 mm electrofusion socket SDR11 24VAC 10bar 16bar black DVGW

3,38 €*

Technical details

  • DIN Standard
    DIN 2501
  • Outer ø
    395 mm
  • Material
    ductile iron (GGG40)
  • Material housing
    ductile iron (GGG40)
  • Opening pressure
    1 bar
  • Material cover
    cast iron GG 40
  • Material seal
    NBR
  • Temperature range
    -20°C - 100°C
  • Surface treatment
    epoxy coating
  • Holes
    12
  • DN
    250
  • Colour
    blue
  • Connection
    DIN flange
  • Length
    600 mm
  • Ball material
    ductile iron/NBR
  • Flange
    PN10
  • EAN
    4019305393003
  • Part number
    0401936
  • Manufacturer
    Profec

Dimensions

  • Ct-1
    471 mm
  • PCD
    350/355 mm
  • L
    600 mm
Technical drawing

Variants

Product number:
Price
Box qty
MSQ
Stock
0401928
63,95 €
48
1
0401929
63,95 €
1
1
0401930
63,95 €
50
1
(8)
0401931
63,95 €
40
1
0401933
63,95 €
22
1
(1)
0401934
63,95 €
14
1
0401935
63,95 €
8
1
0401936
63,95 €
4
1
(1)
0401937
63,95 €
2
1
(4)
